Meta-XY XL

The Meta-XY XL is our high-capacity laser marking platform, engineered for precision and adaptability on a larger scale. Designed and manufactured in the UK, this advanced system is ideal for marking, engraving, or etching large-format parts and panels with unrivalled accuracy.

Built around a generous 1000 x 600 mm working area and compatible with our full portfolio of premium laser sources—including fiber, UV, MOPA, and CO₂—the Meta-XY XL is a powerful and versatile solution for both industrial and high-spec commercial applications.

Find a Vendor Get a Price

Large-Area 3-Axis Laser Marking System

Designed for Scalable Precision

The Meta-XY XL retains all the benefits of the original Meta-XY system but with an expanded footprint to accommodate larger components and batch runs. Whether you’re applying traceability codes, logos, or detailed graphics onto metal, plastics, composites, or coated materials, the XL’s precision motion control and modular architecture allow for seamless integration into your workflow.

This machine is particularly well-suited to industries where marking on panels, enclosures, or multiple parts simultaneously is required. It delivers high-resolution results at speed, without compromising repeatability or durability.

3D Laser Marking

Equipped with 3-axis technology, the Meta-XY effortlessly marks flat, curved, and irregular surfaces with pinpoint accuracy. This makes it the ideal laser part marking machine for industries requiring deep engraving, branding, or traceability on complex components.

Multiple Laser Sources

Fiber Laser (CW or MOPA) – Perfect for marking metals, hard plastics and ceramics with deep engraving or high-speed serialisation. UV Laser – Ideal for delicate or heat-sensitive materials such as medical plastics, glass, or flexible films. CO₂ Laser – Best suited for engraving or marking wood, leather, cardboard and coated substrates.

Precision XY-Axis

The Meta-XY features a fully automated, large-format XY table, designed for batch processing and high-throughput applications. This system enables precise positioning across a wide marking area, allowing multiple parts to be processed in a single cycle without manual intervention.

Meta-XY batch laser marking machine

Videos

Explore the Meta-XY in action. Watch our demonstration videos to see how this laser part marking machine delivers high-speed automation, deep engraving, and perfect contrast on a variety of materials. See real-world applications across aerospace, automotive, and industrial manufacturing.

Prev 1 of 1 Next

Job Control HMI

The Meta-XY’s Job Control HMI provides an intuitive user interface for managing marking parameters, automation sequences, and job queues. Operators can easily configure tasks, adjust settings, and monitor operations in real time.

Aluminium T-Slot Work Table

The precision-engineered aluminium T-slot work table allows for quick installation of jigs, fixtures, and modular add-ons. Designed for repeatability and efficiency, it ensures perfect positioning of parts for every marking cycle.

Uninterrupted 24/7 Operation

Built for high-demand environments, the Meta-XY ensures continuous marking with minimal downtime. Its robust engineering, combined with an industry-leading 10-year warranty, guarantees reliability for round-the-clock production.

180° Access Door

The pneumatic access panel allows for 180° access to the processing area, whilst protecting the user from laser radiation when the system is marking and the door is down.

Logical

Features

From its 180° access door for effortless loading to 24/7 operation and an intuitive Job Control HMI, every aspect is engineered for laser marking parts or projects a breeze.

Industrial-Level

Durability.

Robust and versatile, the Meta-XY XL large-format laser marking machine is built for both commercial and industrial sectors and boasts an incredibly long lifespan exceeding 15 years. Compliant with ISO9001, CE, RoHSII, and FDA regulations.

Harsh Environments

Incorporating top-of-the-range Siemens PLC electronics, each Meta-XY XL gets 3 full days of alignment and testing after leaving production. It’s designed to operate effortlessly in greater variations of dust, temperature and humidity than other systems.

3-10 Year Warranty

We’re so confident in our technology we back it up with some of the longest warranties in the industry. The Meta-XY XL comes with a 3-year warranty as standard, extendable to 10 years.

Insane Endurance

We take your business seriously, that’s why the Meta-XY XL is created with the longest lifespan in mind. Featuring an ergonomic pneumatic door which can withstand 100,000s cycles – you’ll struggle to find a more durable system than this.

Solid Chassis

Strong, durable and built to last. Our Meta-XY XL is robust in it’s makeup, made with military-grade aluminium it operates with full functionality even after knocks and heavy use.

Meta-XY XL

Modular & Future-Proof

Like all our Meta range systems, the Meta-XY XL is fully modular. Whether you need to upgrade the laser source, integrate vision alignment, or add a rotary device later, this machine has been designed to adapt with your business over time.

Choose from a wide selection of lens options, safety features, and hardware modules to build a system tailored to your workflow.

Conveyors

Streamline production with conveyor integration, perfect for high-speed manufacturing lines requiring efficient part flow.

Rotary Systems

Achieve precise cylindrical marking with a rotary axis, ideal for engraving rings, tubes, and round components.

Custom Jigs

Quickly swap out custom jigs for different part geometries, ensuring perfect repeatability and alignment.

Hopper Systems

Automate batch processing with a hopper system, feeding parts into the marking area with precision for high-volume runs.

FLIR Camera Integration

Add real-time FLIR thermal imaging to monitor heat-affected zones during marking for quality control and process optimization.

Collaborative Robots

Enhance automation with a cobot for seamless part handling, reducing manual workload and increasing throughput.

Meta-XY batch laser marking machine

Summary.

The Meta-XY XL offers industrial-grade laser marking performance in a larger format—perfect for manufacturers and workshops looking to process bigger parts or increase productivity through batch marking.

With modular build options, flexible laser source configurations and UK manufacturing at its core, the Meta-XY XL is a robust long-term investment in scalable marking technology.

META-XY batch laser marking machine

Specification

The Meta-XY XL Large-Format laser marking machine is one of the most feature enriched and functional laser marking workstations available today. Designed, assembled, configured and tested here in the UK, it is compliant with CE, RoHSII, ISO9001 and FDA regulations.

In production we take our time, and most importantly we don’t cut corners. By choosing high-grade components and testing rigorously, we can confidently say, at this price point, we feel there really is no other system on the market to compete with the Meta-XY XL.

In Detail

Dimensions (WDH)	1140mm x 1975mm x 1885mm
Laser Source	ELI-X17 MOPA Fiber, ELI-355 UV, or CO2
Laser Head	3D (3-Axis)
3D Depth Of Focus (DOF)	35mm
WaveformsThe number of waveforms is a good indicator of versatility, what materials can be engraved and the effects a laser can a... More	Variable
Accuracy	1µm (0.001mm)
Positioning Speed	10,000mm/s
Z-axis StrokeRough indicator of the maximum part/project height - The Z-Axis is a mechanical vertical adjustment for the laser head. ... More	400mm
Z-axis Accuracy	±0.02mm
DLC / Software	Siemens PLC / Lotus Mark v3.0
International Warranty	3 to 10 years
Max Part Size (Door Open)	Height Restricted Only (Class 4)
Worktable	1000mm x 600mm (T-Slot Expandable)
Accessories Available	Request Catalogue
